VOLPI MRL 2-7
0 Point - 0 Comment
Brand
Category
Stock Status
Stock code
LJ584WGW6V
Hanger Type | 02:01 | Cruising Distance | 33 M. | Static Load | 9000 kg | ||||
Suspension | Cruising Range | Static Load | |||||||
Machine Type | Speed (m/s) | Capacity (kg) | Power (kW) | Pulley (mm) | Current (A) | Pole | Frequency | Speed (rpm) | Torque (Nm) |
Machine Type | Speed (m/s) | Capacity (kg) | Power (kW) | Pulley (mm) | Current (A) | Poles | Frequency | Revolution (rpm) | Torque (Nm) |
VOLPI MRL 2-7 | 0.63 | 3000 | 11.6 | 360x15x8 | 41.1 | 20P | 11.14 | 67 | 1655 |
VOLPI MRL 2-7 | 1 | 3000 | 18.4 | 360x15x8 | 55.7 | 20P | 17.68 | 106 | 1655 |
VOLPI MRL 2-7 | 1.6 | 3000 | 29.4 | 360x15x8 | 78 | 20P | 28.29 | 170 | 1655 |
VOLPI MRL 2-7 | 2 | 3000 | 36.8 | 360x15x8 | 91.8 | 20P | 35.37 | 212 | 1655 |
VOLPI MRL 2-7 | 2.5 | 3000 | 46 | 360x15x8 | 114.8 | 20P | 44.21 | 265 | 1655 |
VOLPI MRL 2-7 | 0.63 | 3000 | 11.6 | 400X11X10 | 41 | 20P | 10.03 | 60 | 1839 |
VOLPI MRL 2-7 | 1 | 3000 | 18.4 | 400X11X10 | 65 | 20P | 15.92 | 95 | 1839 |
VOLPI MRL 2-7 | 1.6 | 3000 | 29.4 | 400X11X10 | 78 | 20P | 25.46 | 153 | 1839 |
VOLPI MRL 2-7 | 2 | 3000 | 36.8 | 400X11X10 | 98 | 20P | 31.83 | 191 | 1839 |
VOLPI MRL 2-7 | 2.5 | 3000 | 46 | 400X11X10 | 115 | 20P | 39.79 | 239 | 1839 |
VOLPI MRL 2-7 | 0.63 | 3500 | 13.5 | 320x19x8 | 47.8 | 20P | 12.53 | 75 | 1717 |
VOLPI MRL 2-7 | 1 | 3500 | 21.4 | 320x19x8 | 65 | 20P | 19.89 | 119 | 1717 |
VOLPI MRL 2-7 | 1.6 | 3500 | 34.3 | 320x19x8 | 91.1 | 20P | 31.83 | 191 | 1717 |
VOLPI MRL 2-7 | 2 | 3500 | 42.9 | 320x19x8 | 107.1 | 20P | 39.79 | 239 | 1717 |
VOLPI MRL 2-7 | 2.5 | 3500 | 53.6 | 320x19x8 | 133.9 | 20P | 49.74 | 298 | 1717 |
