FORCE 22
0 Point - 0 Comment
FORCE 22 - 1.1 | |||||||||||
PRODUCT CODE | ENGINE TYPE | CARRYING CAPACITY | CABIN SPEED | PULLEY DIAMETER | NUMBER OF ROPE | ROPE DIAMETER | ENGINE POWER PS | ENGINE POWER KW | FLOW | BOND | STATIC LOAD |
FC22320 | VVVF | 1100 | Mar.20 | Ø530 | 8 | Ø10 | 12.Feb | 22.0 | 44/A | 38/3 | 8000 |
FC22240 | VVVF | 1275 | Feb.40 | Ø460 | 8 | Ø10 | 12.Feb | 22.0 | 44/A | 38/3 | 8000 |
FC22200 | VVVF | 1700 | 2.00 | Ø530 | 8 | Ø10 | 12.Feb | 22.0 | 44/A | 41/2 | 8000 |
FC22160 | VVVF | 2000 | Jan.60 | Ø460 | 8 | Ø12 | 12.Feb | 22.0 | 44/A | 41/2 | 8000 |
FC22120 | VVVF | 2250 | Jan.20 | Ø400 | 8 | Ø12 | 12.Feb | 22.0 | 44/A | 41/2 | 8000 |
FC22100 | VVVF | 3400 | 1.00 | Ø530 | 8 | Ø12 | 12.Feb | 22.0 | 44/A | 41/1 | 8000 |
FC22080 | VVVF | 3500 | 0.80 | Ø460 | 8 | Ø12 | 12.Feb | 22.0 | 44/A | 41/1 | 8000 |
FC22063 | VVVF | 3500 | 0.63 | Ø400 | 8 | Ø12 | 12.Feb | 22.0 | 44/A | 41/1 | 8000 |
FORCE 22 - 2.1 | |||||||||||
PRODUCT CODE | ENGINE TYPE | CARRYING CAPACITY | CABIN SPEED | PULLEY DIAMETER | NUMBER OF ROPE | ROPE DIAMETER | ENGINE POWER PS | ENGINE POWER KW | FLOW | BOND | STATIC LOAD |
FC2216021 | VVVF | 2200 | Jan.60 | Ø530 | 8 | Ø10 | 30 | 22.0 | 44/A | 38/3 | 16000 |
FC2212021 | VVVF | 2550 | Jan.20 | Ø460 | 8 | Ø10 | 30 | 22.0 | 44/A | 38/3 | 16000 |
FC2210021 | VVVF | 3400 | 1.00 | Ø530 | 8 | Ø10 | 30 | 22.0 | 44/A | 41/2 | 16000 |
FC2208021 | VVVF | 4000 | 0.80 | Ø460 | 8 | Ø12 | 30 | 22.0 | 44/A | 41/2 | 16000 |
FC2206321 | VVVF | 4500 | 0.63 | Ø400 | 8 | Ø12 | 30 | 22.0 | 44/A | 41/2 | 16000 |
FC2205021 | VVVF | 6800 | 0.50 | Ø530 | 8 | Ø12 | 30 | 22.0 | 44/A | 41/1 | 16000 |
FC2204021 | VVVF | 7000 | 0.40 | Ø460 | 8 | Ø12 | 30 | 22.0 | 44/A | 41/1 | 16000 |
FC2203021 | VVVF | 7000 | 0.30 | Ø400 | 8 | Ø12 | 30 | 22.0 | 44/A | 41/1 | 16000 |
