AK 2-7
0 Point - 0 Comment
Hanger Type | 02:01 | Cruising Distance | 51 M. | Static Load | 9000 kg | ||||
Suspension | Cruising Range | Static Load | |||||||
Machine Type | Speed (m/s) | Capacity (kg) | Power (kW) | Pulley (mm) | Current (A) | Pole | Frequency | Speed (rpm) | Torque (Nm) |
Machine Type | Speed (m/s) | Capacity (kg) | Power(kW) | Pulley (mm) | Current (A) | Poles | Frequency | Revolution (rpm) | Torque (Nm) |
AK 2-7 | 0.63 | 2500 | 9.6 | 400x9x10 | 29.8 | 20P | 10.03 | 60.2 | 1532.8 |
AK 2-7 | 1 | 2500 | 15.3 | 400x9x10 | 47.3 | 20P | 15.92 | 95.5 | 1532.8 |
AK 2-7 | 1.6 | 2500 | 24.5 | 400x9x10 | 61.4 | 20P | 25.46 | 152.8 | 1532.8 |
AK 2-7 | 2 | 2500 | 30.6 | 400x9x10 | 76.8 | 20P | 31.83 | 191 | 1532.8 |
AK 2-7 | 2.5 | 2500 | 38.3 | 400x9x10 | 90.3 | 20P | 39.79 | 238.7 | 1532.8 |
AK 2-7 | 0.63 | 3000 | 11.6 | 320x17x8 | 35.7 | 20P | 12.53 | 75.2 | 1471.5 |
AK 2-7 | 1 | 3000 | 18.4 | 320x17x8 | 52.7 | 20P | 19.89 | 119.4 | 1471.5 |
AK 2-7 | 1.6 | 3000 | 29.4 | 320x17x8 | 73.7 | 20P | 31.83 | 191 | 1471.5 |
AK 2-7 | 2 | 3000 | 36.7 | 320x17x8 | 86.7 | 20P | 39.79 | 238.7 | 1471.5 |
AK 2-7 | 2.5 | 3000 | 45.9 | 320x17x8 | 108.4 | 20P | 49.74 | 298.4 | 1471.5 |
